START YOUR GP JOURNEY!

KAYO MINIGP MR150

150cc 4stroke ENGINE

UPSIDE DOWN FORKS

ADJUSTABLE REAR SHOCK

DISC BRAKES

Engine: 150cc 4STROKE

Bore x Stroke: 54mm x 54mm / 58.5mm x 54mm

Compression Ratio: 9.0:1 / 10.0:1

Max Power: 7.1kw (@8000rpm) / 8.1kw/(7700r/min)

Max Torque: 9.5N.m (@6500rpm) / 11.2N/m(5700r/min)

Ignition: CDI

Starter: Kick

Gearshift Pattern: 1-N-2-3-4-5 (1 up, 4 down)

Front Sprocket: 14T

Rear Sprocket: 41T

Chain: KMC 428

Wheelbase: 1074mm

Seat Height: 668mm

Ground Clearance: 123mm

Dry Weight: 85kg

Length x Width x Height: 1556mm x 595mm x 911mm

Frame: Steel

Handle Bars: Steel with Alloy Clip On Clamps

Wheels: Alloy Front 3.00-12, Alloy Rear 3.50-12

Tyres: Front 100/80-12, Rear 120/80-12

Front Forks: USD Fork Travel 100mm

Rear Shock: Adjustable Preload, Common Travel 35mm

Swingarm: Steel Length=410mm

Brakes: Front Brake Disc, Rear Brake Disc

Fork Angle: 23degrees36'

Fuel Capacity: 10 Liters
